The early SM-3 TSRM was made by Thiokol and later ATK. The motor weighs 250 lbs, of which 195 is the dual-pulse multi-grain TP-H-3340A-based propellant.
November 30, 2024 at 1:19 AM
The early SM-3 TSRM was made by Thiokol and later ATK. The motor weighs 250 lbs, of which 195 is the dual-pulse multi-grain TP-H-3340A-based propellant.
Forgot to mention, but the MK.72 is the first stage rocket motor of all these missiles.
October 20, 2024 at 6:05 PM
Forgot to mention, but the MK.72 is the first stage rocket motor of all these missiles.
The rocket motor uses 4 electro-mechanical actuated nozzles made by Parker-Bertea. The nozzles can be deflected +14.5°. The TVC mechanism is a ball and socket. It was made by the Chemical Systems Division of United Technologies.
October 20, 2024 at 6:03 PM
The rocket motor uses 4 electro-mechanical actuated nozzles made by Parker-Bertea. The nozzles can be deflected +14.5°. The TVC mechanism is a ball and socket. It was made by the Chemical Systems Division of United Technologies.
The Mk.72 rocket motor weighs in at 1,500 lbs. It uses an all-boost HTPB-AP propellant grain. It makes up roughly half the weight of each SM. The booster has a burn time of 6 seconds and remains the largest MK.41 VLS-launched booster.
October 20, 2024 at 6:00 PM
The Mk.72 rocket motor weighs in at 1,500 lbs. It uses an all-boost HTPB-AP propellant grain. It makes up roughly half the weight of each SM. The booster has a burn time of 6 seconds and remains the largest MK.41 VLS-launched booster.
Onboard footage from inside the nose cone was recorded by an Instrumented SM-3 KW.
October 20, 2024 at 4:52 PM
Onboard footage from inside the nose cone was recorded by an Instrumented SM-3 KW.
The clam shell removes this unnecessary maneuvering of the TSRM (Third Stage Rocket Motor) and allpws the KW to see the target immediately after the nose cone opens up.
October 20, 2024 at 4:51 PM
The clam shell removes this unnecessary maneuvering of the TSRM (Third Stage Rocket Motor) and allpws the KW to see the target immediately after the nose cone opens up.
This test serves as early de-risking for the jointly developed SM-3 Block IIA variant. Prior Standard Missile variants (SM-3 I/IA/IB) have a nose cone that is ejected. The TSRM has to turn 30° from the direction of the target, eject it, and then face the target again.
October 20, 2024 at 4:49 PM
This test serves as early de-risking for the jointly developed SM-3 Block IIA variant. Prior Standard Missile variants (SM-3 I/IA/IB) have a nose cone that is ejected. The TSRM has to turn 30° from the direction of the target, eject it, and then face the target again.
